One of my goals with mjbots is to make building dynamic robots more accessible to researchers and enthusiasts everywhere. To make that more of a reality, I’m lowering the prices in a big way on the foundational components of brushless robotic systems, the moteus controller and qdd100 servo.

Don’t worry, if you purchased any of these in the last month, you should be getting a coupon in your email equivalent to the difference.

As I am working to improve the gaits of the mjbots quad A1, one aspect I’ve wanted to tackle for a long time is improving the compliance characteristics of the whole robot. Here’s a small step in that direction.

Existing compliance strategy

The quad A1 uses qdd100 servos for each of its joints. The “qdd” in qdd100 stands for “quasi direct drive”. In a quasi direct drive actuator, a low gearing ratio is used, typically less than 10 to 1, which minimizes the amount of backlash and reflected inertia as observed at the output. Then, high rate electronic control of torque in the servo based on current and position feedback allows for dynamic manipulation of the spring and dampening of the resulting system.

https://shop.mjbots.com is now https://mjbots.com (don’t worry, the old site redirects)! The functionality is largely the same, you can still get your qdd100 actuators or moteus controllers. The biggest differences are 1) it looks slightly nicer, and 2) shipping rates are improved, and international shipping rates drastically so. For instance, DHL “Express” 2 day shipping to some points in Europe is now under $35 USD, whereas previously 2 day shipping was over $300. That is often cheaper than even USPS International Priority – which is typically 2-4 weeks.

I made up a YouTube video showing the techniques I used when manufacturing the beta edition of the qdd100 servos TODO link.  Check it out:

I’ve had the qdd100 beta kits available for some time up at mjbots.com, I’m excited to announce that I’ve completed a production run of the beta qdd100’s and they are now available standalone as well.

• mjbots.com: qdd100 beta servo

I look forward to seeing what everyone creates!

As part of provisioning a quad A1, or anytime the mechanical configuration has been changed, I need to go and record where the zero position of all the joints is.  The “0” position for the software now is with the shoulders perfectly horizontal, and the upper and lower leg sticking straight down.

Up until now, every time I’ve done this it has just been by eyeballing and with lots of foam and bubble wrap to shim things into place long enough to record the level.  Sometimes I had to go back and try a few times, as even determining when something is straight is not, well, straightforward.

First, a limited number of qdd100 servos are available for sale to beta testers!  Check them out at mjbots.com.

After building up the first set of qdd100 servos, I wanted to empirically measure their performance parameters.  Some astute commenters uncovered in my terrible juggling video, that I didn’t actually have any ground truth measure of torque with these actuators.  Given that the ultimate torque is a pretty useful performance metric, it’s a good thing to have a solid understanding of.

After I restructured my control laws to take advantage of high rate force feedback for the pronking experiments, I haven’t actually managed to port the walking gait yet.  Now that I have a brand new robot, it seemed like a good time!

This gait is basically the same thing as I ran on the quad A0 in principle.  The opposing feet are picked up according to a rigid schedule, and moved to a point opposite their “idle” position based on the current movement speed.  Any feet that are completely placed on the ground just move with the inverse of the robot’s velocity.
