mjcanfd-usb-1x

While it may not be technically spring outside, it is spring for product announcements here at mjbots, and I’m excited to announce the next evolution of CAN-FD adapter hardware we’re offering, the mjcanfd-usb-1x:

The major changes from the fdcanusb:

  • USB-C instead of USB micro

  • Smaller form factor - 30x18mm

  • PH3 CAN-FD connector instead of DB9

  • Less expensive, only $39

This makes the mjcanfd-usb-1x better suited for in-application deployments and just all around better as a development tool. It can be mounted down more easily, uses the same connector and pinout as moteus, and is compatible with our existing PH3 cables.

New nice to have accessories at mjbots.com

This is a quick post to highlight two new nice to haves at mjbots.com that have been long requested.

First, is a pre-built JST PH3 CAN-FD cable, initially available in 30cm lengths. It can be used to daisy chain between controllers, or connect up a pi3hat. Use it as is, or cut it and strip the wires to easily build a JST PH3 to pigtail cable.

Second, is a pre-built CAN-FD termination resistor that can be directly plugged into a JST PH3 receptacle on the moteus controller. This uses split termination to achieve 5Mbps bandwidth over longer daisy chains than can be achieved with a simple one-resistor terminator.

CAN prefixes for moteus

The moteus controller, communicates exclusively over CAN-FD for command, telemetry, and diagnostics. It will accept either standard or extended frames, and until now, the ID format in terms of bits looked like the following:

33333222222221111111100000000
43210765432107654321076543210
XXXXXXXXXXXXXQSSSSSSSDDDDDDDD

Where:

  • X: Don’t care
  • Q: 1 for query, 0 for no query
  • S: source ID
  • D: destination ID

If the lower 8 bits matched the configured ID, all the X bits would be completely ignored and moteus would accept the CAN message as if it were destined for itself. This may not be super desirable, as it consumes nearly all of the available CAN-FD addressing space.

Unsuccessful CAN-FD communication between CANBed-FD and moteus

On the mjbots discord, people are often looking for the cheapest possible way to command and monitor a moteus controller. One possible solution that comes up over and over again is the CANBed-FD board, as sold by Seeed Studio (and others). I decided to get one of these in house to see if I could make it work:

The first thing I figured out was that the DB-9 connector used a non-standard pinout for CAN_L and CAN_H. I just switched to the terminal block connections instead of the DB-9 to get around that. For the software, I decided to use the acan2517FD Arduino library, as it was quite a bit more robust and featureful than the one provided by Longan Labs.

pi3hat configurable CAN

To date, the pi3hat CAN channels only supported CAN properties suitable for use with moteus controllers. Given that’s what most people are using them for, that’s fine. However, there was no real constraint behind that, just laziness.

Thus, I’ve released new firmware for the pi3hat that supports configuring the bitrate, FD-ness, and other properties of all 5 CAN channels.

Currently only the C++ library exposes the configuration functionality, but it will be easy enough to add to python when someone needs it.

pi3hat r4.4

It seems like all the posts I’m writing these days are for new products! Here’s the pi3hat r4.4:

There are two changes from the previous r4.2. First, it now supports voltage inputs up to 44V. Second, in support of future upgrades, the 5th CAN-FD port has been upgraded to support 8Mbps, but downgraded to no longer have a wide common mode voltage range.

THUS, IT IS NOT SAFE TO CONNECT THE CAN-FD PORT ON THE pi3hat r4.4 TO A power_dist r3.X BOARD.

New cross-platform moteus tools!

After receiving many requests via youtube, discord, and email, I’ve finally gone ahead, bitten the bullet, and updated all of the moteus tools to be pure python and work in a cross platform manner. Now, the only thing you need to do to install pre-compiled versions of tview and moteus tool on most* platforms is:

pip3 install moteus_gui
python3 -m moteus_gui.tview    # (or maybe just tview)
python3 -m moteus.moteus_tool  # (or maybe just moteus_tool)

I’ve personally tested these on Linux, Windows, and Raspberry Pi, and others have at least verified basic operation on Macs. Python 3.7 or greater is required.

moteus and socketcan

Various users have been trying to use lower-cost Raspberry Pi CAN-FD adapters for the moteus controller for some time (like this one from Seeed), but have had problems getting communication to work. I buckled down and went to debug the problem, discovering that the root of the issue was that the linux kernel socketcan subsystem calculates very sub-optimal CAN timings for the 5Mbps bitrate that moteus uses. This results in the adapters being unable to receive frames sent at the actual 5Mbps rate, but instead only slightly slower.

Measuring the pi3hat r4.2 performance

Last time I covered the new software library that I wrote to help use all the features of the pi3hat, in an efficient manner. This time, I’ll cover how I measured the performance of the result, and talk about how it can be integrated into a robotic control system.

pi3hat r4.2 available at mjbots.com

pi3hat r4.2 available at mjbots.com

Test Setup

To check out the timing, I wired up a pi3hat into the quad A1 and used the oscilloscope to probe one of the SPI clocks and CAN bus 1 and 3.
